19mm RFI Emi Honeycomb Air Vent Filter For Faraday Cage Anechoic Chamber high quality

Ask Lasest Price
Model Number :	HZ
Brand Name :	HZ
Supply Ability :	10000 Piece/Pieces per Month
Price :	$100.00
Certification :	CE RoHS

Add to Cart

Product Details
Company Profile

19mm RFI Emi Honeycomb Air Vent Filter For Faraday Cage Anechoic Chamber high quality

EMI RFI shield honeycomb ventilation air filter for faraday cage

Contents	Data	Test Methods
Size	A 300 ~ 630 mm	ESQ-517-23
	B 300 ~ 630 mm
	T 25.4 mm (1 inch)
Cell Size	4.76 mm (3/16 inch)	ESQ-517-23
Shielding Rate	> 100 dB (@100KHz ~ 18GHz)	IEEE-Std-299
Material	Tin plated steel

Brass/Steel/ Stainless steel honeycomb
1. Material:Steel, brass,stainless steel,aluminum
2. standard size: 300x300mm, 300x600mm
3. Standard cell size: 3.2/4.0/4.8mm

4. MOQ 1 piece

Product Features
Honeycomb filter use for shielding room and cabinet
Materials: Steel, brass, Aluminum, Stainless steel
The waveguide vent provides maximum RF attenuation while allowing optimum airflow
We can also produce various customized specification for civil or military use according to customer`s requirements.
High quality, Reasonable price and Short delivery, sample order accept
Technical Specifications
Honeycomb Standard Thickness(mm)	12.5mm/19mm/25mm/50mm
Honeycomb standard size	300x300/300x600/450x450/600x600mm
Hole size	3.2mm/4.0mm/4.8mm
The frame materials	Brass, Steel, Stainless steel
MOQ	1PCS
Shielding Performance
Magnetic field	14KHz≥75dB 150KHz≥100dB
Electric field	200KHz-50MHz≥110dB
Flatwave	50MHz-1GHz≥110dB
Microwave	1GHz-10GHz≥100dB 10GHz-18GHz≥90dB
